Water Jet

OMAX Maxiem 2040 Water Jet

Table Size: 15' 9" x 6' 9"
(4,801 mm x 2,057 mm)

X-Y Cutting Travel: 13' 4" x 6' 7"
(4,064 mm x 2,007 mm)

Motorized Z-axis with nozzle

High pressure pump

CNC Mills

1996 Mazak VTC-16B Vertical Milling Center
	Working Envelope of 20" x 16" x 44" 7000 RPM Spindle 24 Tool Rigid Tapping
1996 Mazak VTC-20B Vertical Milling Machine
	Working Envelope: 20" x 20" x 44" 7000 RPM Spindle 24 Tool Rigid Tapping Full funtional 4th Axis
1998 Mazak VTC-20B Vertical Milling Machine
	Working Envelope: 20" x 20" x 44" 7000 RPM with Through Spindle Coolant. 24 Tool Rigid Tapping
2000 Mazak VTC-200B Vertical Milling Machine
	Working Envelope: 20" x 20" x 44" 10000 RPM, with Through Spindle Coolant 24 Tool Rigid Tapping Chip Conveyor
2012 Mazak Vertical Milling Center Nexus 510C-II
	Working Envelope of 20" x 20" x 41.3" 12000 RPM, with High Pressure Through Spindle Coolant 30 Tool Rigid Tapping Chip Conveyor Full funtional 4th Axis
2004 Fanuc Robodrill Vertical Milling Center
	Fanuc Controller 20,000 RPM, with High Pressure Through Spindle Coolant 21 Tool Rigid Tapping Pallet Changer with Dual 4th Axis
2004 Fanuc RoboDrill Vertical Milling Center
	Fanuc Controller 15,000 RPM Spindle 21 Tool Rigid Tapping
2008 Fanuc RoboDrill Vertical Milling Center
	Fanuc Controller 24,000 RPM, with High Pressure Through Spindle Coolant 21 Tool Rigid Tapping Pallet Changer

1997 Mazak Super Quick Turn 15MS Mark II
	25HP , 5000 RPM, and 2" diameter bar through, on main spindle 3500 RPM on live tooling 8" chuck on main and 11 3/4" swing diameter, 6" chuck on sub rigid tapping on live tooling
2003 Mazak Super Quick Turn Nexus 200
	25HP , 5000 RPM, and 2" diameter bar through spindle 8" chuck and 11 3/4" swing diameter 12 tool Programmable Tail Stock 24" between centers
Hyundai HT-160M
	5500 RPM spindle 6" chuck 4000 RPM on live tooling 10 position Live tooling
Hyundai HT-180
	5500 RPM spindle 6" chuck 10 position tooling

Grizzly Model G0509G 16" x 40" Lathe
	Varible speed spindle Multi chuck X - Z Digital reed outs.
Wyong Sheer
	52" Cut 10 GA Steel 1/4" Aluminum
HYD-MECH HSV-250 Automatic Saw
	12" x 12" Capacity Through Cut Auto lenght preset Varible speed settings
Piranha Press Brake 60"
	60" Capacity Gen II Contorl System Automatic

Welding & Fabricating

Mig, Tig and Stick Welding

Full Jig and fabricating capiblity

2 - Precision 4' x 8' Demmeler Welding Tables

Complete line of precision Demmeler components

Mitutoyo B231 CMM
	32" x 32" x 16" Networked Computer Back Up.
Full Inventory of Quality Inspection Tools
	Contour Projector Gauges Inspection varified by Quality Manger (Bill Whitelock)
